New LXC3120 diesel Auto generator controller replacement of DSE3110/DSE3120

FOB Reference Price:Get Latest Price
US $100-150 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
LIXiSE
Model Number:
LXC3120
is__customized:
YES
SupplyAbility
SupplyAbility:
3000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
standard export packaging
Port
Shenzhen
Lead Time :
7days



New LXC3120 diesel Auto generator controller replacement of DSE3110/DSE3120





Product introduction:

Product performance and features:

1. LCD liquid crystal display (LCD) is 132 x 64, four languages (simplified Chinese, English, Spanish, Russian) showed that light touch button;

2. Suitable for three phase four wire, single-phase second-line, three-phase three-wire, two phase three line (120 v / 120 v) power frequency 50 hz or 60 hz system;

3. The acquisition and display/electric power three-phase voltage, three-phase current, frequency and power parameters;

4. The utility has the function of overvoltage, undervoltage, phase, power generation has over voltage, under voltage, frequency, frequency, flow function;

Various parameters: 5. Precision engine cooling water temperature, oil pressure, fuel quantity, mechanical and electrical charging pressure, and according to the set, effectively protect the engine to avoid engine accidental damage;

6. Control protection function: diesel generating set automatic starting/stopping, break-brake switch (ATS) and perfect fault display protection function;

7. A power outage, idle speed control, preheating control, speed control, and all are relay output;

8. Function parameter Settings: allows the user to change the parameters setting, when the system power will not be lost, all parameters can be adjusted from the controller front panel controller, or the use of a PC through USB programming interface adjustment;

9. A variety of temperature and pressure sensors can be used directly, and can custom parameters;

10. A variety of start-up success conditions (speed sensor, oil pressure, power generation) can choose;

11. A wide range of power supply (8 ~ 35) VDC, able to adapt to different starting battery voltage environment;

12. Modular structure design, the flame retardant ABS shell, pluggable terminal blocks, embedded installation, compact structure, convenient installation


Specification:

Continuous working voltage: DC8.0 V to 35.0 V power supply
The machine power consumption: < 3 w (standby mode: 2 w or less)
Alternator voltage input: 15 V AC 360 V AC (phN)
15 V AC 360 V AC three-phase four-wire (phN)
Two phase three line 15 V AC 360 V AC (phN)
30 V AC 620 V AC single-phase secondary (PHPH)
Three-phase three-wire
Ac generator frequency 50 Hz / 60 Hz
Speed sensor voltage: 1.0 to 24 v (RMS)
Speed sensor frequency: biggest 10000 hz
Starter relay output: 5 a DC28V dc power supply output
1: programmable relay output 5 a DC28V dc power supply output
2: programmable relay output 5 a DC28V dc power supply output
3: programmable relay output 5 a DC28V dc power supply output
4: programmable relay output 5 a AC250V passive output
5: programmable relay output 5 a AC250V passive output
Dimensions: 143 mm x 115 mm x41mm
Hole size: 110 mm x 90 mm
Ct (current transformer) secondary current, rated: 5 a
Working conditions: temperature (25 ~ 70) : (20 ~ 93 ° C, humidity) % RH
Storage conditions: temperature: (30 ° C ~ + 80)
Protection grade: IP55: when equipped with waterproof rubber ring between controller and the control panel.
IP42: when no add waterproof rubber ring between controller and the control panel.
Dielectric strength: object: between the input/output/power supply
Reference: IEC688-1992
Test method: AC1.5 Kv / 1 min 3 ma leakage current
Weight: to be determined
